Subaru stand-alone interface box

The Subaru interface box as an all in one interface comprising of all the fuses, relays, connectors, diagnostics. indicators lamps and even an onboard OBDII diagnostic port.
It is designed to replace all the loose modules, relays and connectors and house them all in one enclosure. The interface box also includes fuses and radiator fan relays, eliminating the needs to install extra hardware to run these components.
The interface box also includes add on options such as a Canbus emulator, fuel system emulator and variable speed fuel pump emulator (for 02+ turbo and H6 engines).
"Test Mode" and "Read Memory" subaru connectos are replaced with on-board toggle switches. A toggle switch selects between constant OBDII power and switched OBDII power. This enables an OBDII scanner (or bluetooth module) to be able to be plugged into the OBDII port permanently without flatening the vehicle battery.

Designed to work on just about all OEM Subaru EFI wiring systems, from the 1990s EJ22 all the way to current model Canbus/electronic throttle systems, with provision for powering the Subaru automatic transmission.

The interface shaves up to several hours off the harness modification time and also simplifies and speeds up the electrical install to the vehicle.

The unit comes complete with an enclosure with suitable wiring holes. The unit does not come with relays, as it is intended for the Subaru relays to be re-used from the donor harness. The relays are standard "Micro ISO" relays.
The canbus emulator and fuel/variable fuel pump emulator are available as options at time of ordering.


Click here to download the Manual

For detailes on a basic (economical) version of this product check out the Subaru Interface Board

Check out the two video demonstration of the interface board, from a simple early 90s EJ22 to a more complicated 2010s EZ36 6 Cylinder.
